Makita

10 Gauge Nibbler - JN3201

Name: 10 Gauge Nibbler - JN3201
Brand: Makita
SKU: JN3201
Price: 799 USD
Availability: InStock

SKU: JN3201

MPN: JN3201

Stock Item: Typical lead time for Makita products is 1-2 weeks.

UPC: 088381637770

$799.00 each

Hurry up! Current stock:

Quantity:

Product Description

The Makita 10 Gauge Nibbler (model JN3201) features a powerful 6.2 Amp motor for continuous operation in up to 10-gauge mild steel or 13-gauge stainless steel. A built-in thickness gauge means more convenience, and all ball and needle bearings promote longer tool life. The Makita JN3201 also features easy punch and die replacement for less downtime, and double insulation for longer tool life. The JN3201 is engineered for less noise (only 81 dB(A)) for continuous operation.

Features

Easy punch and die replacement for reduced downtime on the job
Highly visible line-of-sight for precise pattern following
Refined design at only 7.4 lbs.
Convenient chip disposal below cutting material to minimize damage to cutting surface
Hex wrench storage on the tool for operator convenience
Ideal for metal cutting up to 10 gauge mild steel and 13 gauge stainless steel
Built-in thickness gauge for added convenience
Lock-on switch for continuous operation
Small cutting radius (4-3/4" inner edge, 5-1/16" outer edge) for precision applications
Less noise at 81 dB(A) for continuous operation
Well balanced with a rubberized soft grip handle for greater comfort

Manuals

Instruction Manual

Documents

Parts Breakdown

JN3201 FE

Specifications

Cutting Radius (inner edge)	4-3/4"
Power Type	Corded
Capacity (aluminum, ga.)	10 ga.
Capacity (mild steel, ga.)	10 ga.
Capacity (stainless, ga.)	13 ga.
Cutting Radius (outer edge)	5-1/16"
AMPS	6.2
Strokes Per Minute	1,300 SPM
Length	8-1/2 in
Weight	7.5 lbs
