3M Products & Supplies

3M™ Industrial Sealing Tape IS1, White, 60 in x 36 yd, 1 Roll/Case - 7100377266

SKU: 7100377266
MPN: 7100377266
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060762702
3M ID: 70011146084
$1,471.08 each
Hurry up! Current stock:

Product Description

3M™ Industrial Sealing Tape IS1 provides an easy sealing method that creates a moisture barrier under panels or where rivets, screws, or nails are present in automotive, specialty vehicle, electronic and heating, ventilation, and cooling (HVAC), and wind energy applications. This conformable tape is engineered with a waterproof membrane and acrylic adhesive that helps protect interior environments from leakage at joints, including panels, floors, trim, and frames, by sealing around the fastener for a secure seal. Designed for reliability, the product provides an easy-to-use and effective alternative to slow-curing and messy liquid sealants while offering robust adhesion that sticks to most substrates. Because of the versatility of the tape, it can be applied in temperatures as low as 0 °F (-18 °C) with an operating temperature range of -40 °F to 240 °F (-40 °C to 116 °C). 3M™ Industrial Sealing Tape IS1 excels in water leak prevention, including sealing around RV windows, automotive frames, interior joints in HVAC systems, the tops of electrical enclosures, and more. For a tight water seal, explore the sealing potential of this tape in your next industrial application.

Features

  • FASTENER SEALABILITY: Securely seals around rivets, screws, staples, and nails to prevent moisture intrusion
  • ENDURES VARYING TEMPERATURES: Can be applied in temperatures as low as 0 °F (-18 °C) with an operating temperature range of -40 °F to 240 °F (-40 °C to 116 °C)
  • DIVERSE INDUSTRIES: Excels in water leak prevention in automotive, specialty vehicle, HVAC, wind energy, and signage
  • HIGHLY CONFORMABLE: Designed with a thin, flexible backing that can fit in between panels and tight spaces
  • RELIABLE WATER PROTECTION: Engineered with a waterproof membrane and acrylic adhesive that helps protect interior environments from leakage at critical joining areas
  • AGGRESSIVE ADHESIVE: Forms a strong bond on various surface types, including anodized aluminum, galvanized metal, fiberglass, plywood, and more
Spec Sheet



Downloads

Specifications

Shelf Life730
Core Size (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Imperial) UOMlb/in
Country of OriginUnited States
Face Side Adhesive Thickness (Metric) UOMmm
Overall Width (Imperial)60.0
Application Temperature To (Celsius) UOMDegree
Minimum Operating Temperature (Fahrenheit)-40.0
Product TypeSealing Tape
Face Side Adhesive Thickness (Metric)0.13
Application Temperature From (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)240.0
Application Temperature To (Celsius)66.0
Total Tape Thickness without Liner (Metric)0.25
Overall Length (Imperial)36.0
Shelf Life UOMMonth
Specifications MetASTM E2178
Core Size (Imperial) UOMin
Face Side Adhesive Thickness (Imperial)5.0
Application Temperature From (Celsius)-18.0
Number of Adhesive SidesSingle-sided
Core Size (Metric)76.2
Overall Width (Imperial) UOMin
Adhesion to Steel57 N/100mm (52 oz/in)
Overall Length (Imperial) UOMyd
Overall Length (Metric)32.918
Maximum Operating Temperature (Celsius)116.0
Primary Liner Thickness (Imperial)6.0
Adhesive TypeAcrylic
Indoor/OutdoorBoth
Tensile Strength (Imperial)22.0
Backing Thickness (Imperial)5.0
Backing Thickness (Imperial) UOMmil
Elongation at Break>700%
Overall Length (Metric) UOMm
Primary Liner Thickness (Metric) UOMmm
Tensile Strength (Metric) UOMN/100mm
Overall Width (Metric)1524.0
Face Side Adhesive Thickness (Imperial) UOMmil
Backing Thickness (Metric) UOMmm
Primary Liner Thickness (Imperial) UOMmil
Product ColorWhite
Primary Liner Thickness (Metric)0.16
Maximum Operating Temperature (Fahrenheit) UOMDegree
Tensile Strength (Metric)385.0
Total Tape Thickness without Liner (Metric) UOMmm
ApplicationAppliance; Automotive; Electronics; General Industrial; Metalworking; Military & Government; Specialty Vehicles; Transportation
Total Tape Thickness without Liner (Imperial)10.0
Backing (Carrier) MaterialMultilayer Elastomeric Film
Maximum Operating Temperature (Celsius) UOMDegree
Face Side Adhesive TypeAcrylic
Minimum Operating Temperature (Celsius)-40.0
Core Size (Imperial)3.0
Backing Thickness (Metric)0.13
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Imperial) UOMmil
