3M Products & Supplies

3M™ Shearbolt Connector QCI 350-750-U, 350-750 kcmil, 1 /Case - 7100369043

SKU: 7100369043
MPN: 7100369043
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060581440
3M ID: 80000240731
$278.67 each
Hurry up! Current stock:

Product Description

3M™ QCI Shearbolt Splice Connector is ideal for connecting aluminum, copper and aluminum to copper conductors. Its aluminum construction offers high conductivity and an electro tin plated finish resists corrosion. Tapered ends enable smooth splice body transition from the connector to the cable. For applications up to 69 kV and withstands temperatures of 221 °F (105 °C).

Features

  • Ideal for connecting copper, aluminum or transition from copper to aluminum conductors
  • Size 5.12-in x 1.3-in O.D.
  • Accommodates wire size of 1/0 AWG to 350 kcmil (stranded)
  • Made of aluminum for good conductivity and has corrosion-resistant tin plating
  • Built-in center stop enables correct positioning
  • Stepless shearbolt barrel and contact pad ensures optimun contract pressure for reliable performance and mechanical pull-out strength

Downloads

Specifications

Product TypeLug
Minimum Conductor Size (Imperial)350 kcmil
Outer Diameter (Imperial) UOMin
Connector DescriptionOne Hole
For Use WithAluminum and/or Copper Conductors
Barrel StyleShearbolt
ApplicationCable Connection
Electrical Connector TypeShearbolt Connectors
Outer Diameter (Metric) UOMmm
Stud Hole Quantity6.0
Product SeriesQCI
Outer Diameter (Metric)41.9
Minimum Conductor Size (Metric)185 mm²
Maximum Conductor Size (Imperial)750 kcmil
Country of OriginUnited States
Voltage ApplicationMedium Voltage
Outer Diameter (Imperial)1.65
