Scotch® High Performance Fine Line Tape 4740, 25 mm x 50 m, 48 Roll/Case - 7100382014

Name: Scotch® High Performance Fine Line Tape 4740, 25 mm x 50 m, 48 Roll/Case - 7100382014
Brand: 3M Products & Supplies
SKU: 7100382014
Price: 3384.63 USD
Availability: InStock

Sold As: 48-Pack

SKU: 7100382014

MPN: 7100382014

Stock Item: Stock items typically ship within 2-3 business days

UPC: 00068060763556

3M ID: UU013916018

$3,384.63 ($70.51 / Count)

Hurry up! Current stock:

Quantity:

Product Description

Scotch® High Performance Fine Line Tape 4740 is a pressure-sensitive, solventless adhesive tape engineered to resist lifting and withstand high temperatures for two-tone paint applications in automotive OEM, specialty vehicle, and the aerospace markets. With a tape thickness of 5.2 mil (0.13 mm), it meets the demands of challenging operations and is designed to remove cleanly with no edge residue, delivering professional and consistent results. Its exceptional conformability allows instant and secure adhesion onto steel, intricate surfaces, depressed areas, and sharp curves. The versatility of the tape makes it ideal for precision work involving simple or complex patterns in automotive fascia, custom two-tone, and other critical masking applications. Scotch® High Performance Fine Line Tape 4740 can endure multiple paint-bake cycles, handling temperatures as high as 320 °F (160 °C) for up to 60 minutes and 356 °F (180 °C) for up to 10 minutes. The water-based adhesive reduces solvent usage during product formulation and manufacturing by 80% compared to similar 3M solvent-based fine line tapes. These benefits of excellent conformability, high-temperature resistance, clean removal, and a solventless adhesive allow this tape to deliver professional paint lines and reduce inefficiencies or rework caused by adhesive residue and ghosting. Elevate your operations with this reliable solution that helps you achieve crisp paint lines and a quality application.

Features

HIGH-TEMPERATURE RESISTANCE: Operates in temperatures as high as 320 °F (160 °C) for up to 60 minutes and 356 °F (180 °C) for up to 10 minutes
SOLVENTLESS ADHESIVE TECHNOLOGY: Uses a pressure-sensitive, solventless adhesive that adheres to complex surfaces and resists lifting, even on irregular areas
HIGHLY VERSATILE: Ideal for precision work involving simple or complex patterns in automotive fascia, custom two-tone, and other critical masking applications
REMOVES CLEANLY: Designed to remove cleanly with no edge residue or ghosting, delivering professional and consistent results
FOR CRITICAL PAINT APPLICATIONS: Expertly formulated for two-tone paint applications in the automotive OEM, specialty vehicle, and aerospace markets
EXCEPTIONAL CONFORMABILITY: Allows instant and secure adhesion to steel, intricate surfaces, depressed areas, and sharp curves

Spec Sheet

Downloads

Document Brochures

Safety Data Sheet

Spec Sheet

Specifications

Shelf Life	547
Application	Automotive Masking; Fascia Painting; Fine Line Masking; Fine Lines; Masking Solution; Masking for Painting; Paint Baking; Paint Masking; Paint Preparation Masking; Premium Masking; Surface Preparation for Painting
Overall Width (Metric)	25.0
Overall Length (Imperial) UOM	yd
Maximum Operating Temperature (Fahrenheit) UOM	Degree
Backing (Carrier) Material	Polyolefin FIlm
Overall Width (Imperial) UOM	in
Adhesive Type	Acrylic
Clean Removal	Yes
Core Size (Metric)	76.2
Core Size (Imperial) UOM	in
Overall Length (Metric) UOM	m
Tensile Strength (Metric) UOM	N/cm
Shelf Life UOM	Month
Overall Width (Metric) UOM	mm
Country of Origin	Japan
Performance Level	Specialty High Temperature
Tensile Strength (Metric)	42.7
Maximum Operating Temperature (Fahrenheit)	356.0
Features	Clean Removal; Easy to Use; Removable; Residue-free Removable
Maximum Operating Temperature (Celsius)	180.0
Core Size (Imperial)	3.0
Industries	Aerospace, Automotive, Specialty Vehicles, Transportation
Indoor/Outdoor	Indoor
Core Size (Metric) UOM	mm
Overall Length (Metric)	50.0
Elongation at Break	1353%
Maximum Operating Temperature (Celsius) UOM	Degree
Overall Width (Imperial)	0.984
Overall Length (Imperial)	54.681
Product Color	Yellow
