3M Products & Supplies

Scotch® Vinyl Electrical Tape Super 88, 3/4 in x 66 ft, Black, 10 rolls/carton, 100 rolls/Case - 7000006092

Sold As: 100-Pack
SKU: 7000006092
MPN: 7000006092
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00054007061434
3M ID: 80610833867
5 Digit UPC: 6143
$996.41 ($9.96 / Count)
Hurry up! Current stock:

Product Description

Scotch® Vinyl Electrical Tape Super 88 is an all-weather, premium-grade tape created to provide a protective jacket and primary electrical insulation for splices up to 600V, with a total thickness of 8.5 mil (0.216 mm) when applied. The thickness of the tape broadens the range of applications, particularly heavy-duty operations. This tape is engineered with pressure-sensitive rubber resin adhesive and elastic PVC backing, providing electrical and mechanical protection for a variety of applications. It is known for its strength and reliability, excelling in extreme indoor and outdoor conditions to help protect electrical conductors from UV exposure. Whether the application involves low-voltage primary or secondary insulation, cable jacketing, or mechanical protection and padding, Scotch® Vinyl Electrical Tape Super 88 offers excellent insulation and adhesion properties. Meeting the requirements for flame retardancy, the tape can be used within temperatures from 0 °F to 221 °F (-18 °C to 105 °C) and is UL 510 Listed, CSA C22.2 No.197 and VDE Mark Certificate no. 130462; Type 7: IEC 60454-3-1-7/F-PVCP/90, IEC 60454-3-1-7/F-PVCP/90 Certified, and RoHS Compliant. Discover this tape for reliable environmental protection and performance.

Features

  • TEMPERATURE-RESISTANT: Performs within temperatures from 0 °F to 221 °F (-18 °C to 105 °C)
  • RELIABLE PERFORMANCE: Provides a protective jacket and primary electrical insulation for splices up to 600V in harsh indoor, extreme, and exposed outdoor applications
  • ENDURES THE ELEMENTS: Protects in extreme environments, making it a reliable solution for long-lasting performance
  • BUILT STRONG: Engineered with a rubber-resin adhesive, PVC backing, and heavy tape thickness for excellent electrical and mechanical protection that promotes faster build-up with fewer wraps
  • MULTI-PURPOSE: Excels in low-voltage primary and secondary insulation, cable jacketing, mechanical protection, and padding
  • ENHANCED DEFENSE: Provides additional protection for LV/MV/HV joints and splices when used as an overwrap with rubber splicing and mastic tapes
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginUnited States
Minimum Operating Temperature (Celsius)-18.0
ApplicationElectrical Maintenance; Insulation
Voltage Rating600 V
Specifications MetCSA Certified, IEC 60454-3-1-7/F-PVC P/90, UL Listed, VDE Marks License
Maximum Operating Temperature (Celsius)105.0
Overall Width (Imperial)0.75
Shelf Life UOMYear
Minimum Operating Temperature (Celsius) UOMDegree
Overall Width (Metric) UOMmm
Product CategoryElectrical Tapes
Maximum Operating Temperature (Fahrenheit)220.0
Backing (Carrier) MaterialPVC
Total Tape Thickness without Liner (Imperial)8.5
Overall Length (Imperial)66.0
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Imperial) UOMmil
Insulation Resistance> 10^6 megohms
Overall Width (Metric)19.0
Maximum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial) UOMin
Overall Length (Metric) UOMm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Elongation at Break250
Total Tape Thickness without Liner (Metric)0.216
Overall Length (Imperial) UOMft
Overall Length (Metric)20.0
