3M Products & Supplies

3M™ Adhesive Transfer Tape 9498, Clear, 48 in x 60 yd, 2 mil, 1 Roll/Case - 7010372836

SKU: 7010372836
MPN: 7010372836
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200407895
3M ID: 70006255726
5 Digit UPC: 40789
$719.96 each
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 9498 offers excellent flying splice and core starting wet grab characteristics. It is typically used in the printing industry and performs well at process speeds exceeding 2,000 feet per minute. This tape can be used in ovens up to 450ºF (232ºC) if dwell times are ten seconds or less and up to 250⁰F (232⁰C) for longer periods.

Features

  • Bonds well to most substrates, including low surface energy plastics
  • 60lb Densified Kraft (DK) liner for ease in die-cutting operations
  • Moderate temperature resistance up to 250⁰F (121⁰C)
  • Conformable to irregular surfaces
  • Ultra-high peel strength and excellent shear strength to withstand rigorous splicing applications
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial)48.0
Primary Liner Thickness (Imperial)3.5
Adhesive TypeAcrylic
Total Tape Thickness without Liner (Imperial)2.0
Overall Length (Metric)54.86
Primary Liner Thickness (Imperial) UOMmil
Units per Case UOMRoll
Primary Liner Thickness (Metric)0.09
Overall Width (Metric) UOMmm
Overall Length (Imperial) UOMyd
IndustriesPaper
Units per Case1.0
Primary Liner60# Densified Kraft Paper
Minimum Operating Temperature (Fahrenheit)-60.0
Total Tape Thickness without Liner (Imperial) UOMmil
ApplicationZero-Speed and General Splicing
Minimum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Fahrenheit)250.0
Overall Width (Imperial) UOMin
Overall Length (Imperial)60.0
Total Tape Thickness without Liner (Metric)0.05
Primary Liner ColorTan
Total Tape Thickness without Liner (Metric) UOMmm
Overall Length (Metric) UOMm
Primary Liner Thickness (Metric) UOMmm
Overall Width (Metric)1219.2
