3M Products & Supplies

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1315H, Yellow, 16 in x 36 yd, 15 mil, 1 Roll/Case - 7100315115

SKU: 7100315115
MPN: 7100315115
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060006165
3M ID: 70007559415
$894.55 each
Hurry up! Current stock:

Product Description

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1315H with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This yellow foam mounting tape provides high quality medium soft combination print.

Features

  • Has higher plate side adhesion for challenging print conditions that use thick plates or small print sleeves
  • Securely bonds the flexographic photopolymer plate to the print sleeve or steel cylinder to prevent plate edge lifting during printing
  • Yellow foam color indicates the medium soft density foam
  • 0.015 inch (0.38 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to resist edge lifting on flexographic print plates
  • Has a medium soft density foam that is ideal for printing combinations of solids and process with halftone dots
  • Print plates mounted on E1315H will have no air bubbles under the plate due to the air release feature designed into the tape
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
ApplicationFlexographic Plate Mounting
Warranty Period2 Years from Date of Manufacture
Backing MaterialPolyethylene Foam
Urethane SleevesYes
Overall Width (Imperial) UOMin
Overall Length (Imperial)36.0
Overall Width (Imperial)16.0
Overall Length (Metric)32.918
Clean RemovalYes
Product ColorYellow
Primary Liner Thickness (Metric)0.11
Overall Length (Metric) UOMm
Overall Width (Metric)406.4
Application Thickness (Imperial) UOMmil
Primary Liner Thickness (Metric) UOMmm
Application Thickness (Metric) UOMmm
Primary LinerPolycoated Polyester
Adhesive TypeDifferential Acrylate
IndustriesPrint
Print QualityCombination Printing - Medium Soft
Print Quality (Series)13 Series
Shelf Life UOMMonth
Application Thickness (Imperial)15
Application Thickness (Metric)0.381
