3M Products & Supplies

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1815H, Blue, 18 in x 36 yd, 15 mil, 1 Roll/Case - 7100314504

SKU: 7100314504
MPN: 7100314504
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005700
3M ID: 70007559605
$952.76 each
Hurry up! Current stock:

Product Description

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1815H with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This blue foam mounting tape provides high quality firm combination print.

Features

  • Blue foam color indicates the firm density foam
  • Has higher plate side adhesion for challenging print conditions that use thick plates or small print sleeves
  • Has a firm density foam that is ideal for printing combinations of solids and process with halftone dots
  • Print plates mounted on E1815H will have no air bubbles under the plate due to the air release feature designed into the tape
  • 0.015 inch (0.38 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to resist edge lifting on flexographic print plates
  • Securely bonds the flexographic photopolymer plate to the print sleeve or steel cylinder to prevent plate edge lifting during printing
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Metric) UOMmm
Clean RemovalYes
Overall Width (Imperial)18.0
Application Thickness (Metric) UOMmm
IndustriesPrint
Warranty Period2 Years from Date of Manufacture
Urethane SleevesYes
Overall Width (Imperial) UOMin
Overall Length (Metric)32.918
Adhesive TypeDifferential Acrylate
Backing MaterialPolyethylene Foam
Primary Liner Thickness (Imperial)4.5
Product ColorBlue
Overall Width (Metric)457.2
Print QualityCombination Printing - Firm
Application Thickness (Imperial)15
Overall Length (Metric) UOMm
Overall Length (Imperial) UOMyd
Overall Length (Imperial)36.0
Primary LinerPolycoated Polyester
Print Quality (Series)18 Series
Primary Liner Thickness (Metric)0.11
Shelf Life UOMMonth
Primary Liner Thickness (Metric) UOMmm
Application Thickness (Metric)0.381
Primary Liner Thickness (Imperial) UOMmil
Application Thickness (Imperial) UOMmil
