3M Products & Supplies

3M™ Double Coated Tape 9576B, Black, 2 in x 60 yd, 4 mil, 24 Roll/Case - 7000123827

Sold As: 24-Pack
SKU: 7000123827
MPN: 7000123827
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00021200404771
3M ID: 70006257797
5 Digit UPC: 40477
$347.76 ($14.49 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9576B is a medium tack double-sided tape designed for general splicing and roll closing applications. It has a pressure sensitive adhesive that offers a balance of high initial adhesion and good holding power for web splicing and general purpose bonding applications.

Features

  • Medium tack double coated tape is ideal for general splicing, core starting and roll closing
  • Conformable to irregular surfaces
  • Bonds well to most substrates, including low surface energy plastics
  • Double sided adhesion increases dimensional stability for easy handling
  • Excellent peel and shear strength to withstand splicing applications
  • Excellent UV and heat resistance
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Imperial) UOMin
IndustriesGeneral Industrial, Paper, Print
Backing (Carrier) Thickness (Metric) UOMmm
Primary Liner ColorTan
Primary Liner Thickness (Metric)0.1
Total Tape Thickness without Liner (Imperial)4.0
Units per Case24.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Imperial) UOMmil
Face Side Adhesive Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)165.0
Face Side Adhesive Thickness (Metric)0.04
Face Side Adhesive Thickness (Imperial)1.5
Primary Liner Thickness (Metric) UOMmm
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.1
Backing (Carrier) MaterialPolypropylene Film
Primary Liner Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric)0.025
Minimum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Fahrenheit)-40.0
Maximum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Primary Liner Thickness (Imperial)4.0
Product ColorBlack
Overall Width (Metric)50.8
Back Side Adhesive Thickness (Imperial) UOMmil
Overall Length (Metric)54.86
Back Side Adhesive Thickness (Metric) UOMmm
Primary Liner60# Densified Kraft Paper
Overall Length (Metric) UOMm
Back Side Adhesive Thickness (Metric)0.04
Overall Width (Metric) UOMmm
Back Side Adhesive Thickness (Imperial)1.5
Minimum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Celsius)52.0
Overall Width (Imperial)2.0
Backing (Carrier) Thickness (Imperial)1.0
Minimum Operating Temperature (Celsius)-40.0
Face Side Adhesive Thickness (Metric) UOMmm
Overall Length (Imperial)60.0
