3M Products & Supplies

3M™ Double Coated Tape 9576, Clear, 24 in x 60 yd, 4 mil, 1 Roll/Case - 7000049018

SKU: 7000049018
MPN: 7000049018
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200742873
3M ID: 70006358835
5 Digit UPC: 74287
$472.72 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9576 is a medium tack tape for general splicing and roll closing applications. This tape offers ultra-high peel strength and excellent shear strength for durability. It is conformable to irregular surfaces and offers excellent UV and heat resistance.

Features

  • Bonds well to most substrates, including low surface energy plastics
  • Conformable to irregular surfaces
  • Double sided adhesion increases dimensional stability for easy handling
  • Medium tack double coated tape for roll-to-roll splicing, core starting and roll closing
  • Excellent UV and heat resistance
  • Excellent peel and shear strength to withstand rigorous splicing applications
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Length (Metric) UOMm
Maximum Operating Temperature (Celsius)50.0
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial) UOMin
Overall Thickness (Imperial) UOMmil
Overall Width (Imperial)24.0
Units per Case1.0
Backing (Carrier) MaterialPolypropylene
Backing (Carrier) Thickness (Imperial) UOMmil
Master Size Width (Imperial)27.0
Total Tape Thickness without Liner (Imperial)4.0
Shelf Life in Months (From Date of Manufacture) UOMMonths
Full Cure Time24 Hours @ 72 F (22 C)
Shelf Life in Months (From Date of Manufacture)9.0
Primary Liner Thickness (Metric)0.1
Master Size Length (Imperial) UOMLinear
Face Side Adhesive Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)165.0
Face Side Adhesive TypeHigh Tack Acrylic 400
Master Size Width (Metric)69.0
Tape TypeSingle Coated
Minimum Operating Temperature (Fahrenheit)-40.0
IndustriesGeneral Industrial, Paper, Print
Overall Length (Imperial) UOMyd
Master Size Length (Metric) UOMm
Carrier MaterialPolypropylene
Face Side Adhesive Thickness (Metric) UOMmm
Master Size Length (Imperial)360.0
Backing (Carrier) Thickness (Metric) UOMmm
Specific Gravity8.7 Pound Per Gallon (US)
Master Size Length (Metric)329.2
Carrier Thickness UOMmil
Product FormRoll
Master Size Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric)0.1
Total Tape Thickness without Liner (Metric) UOMmm
ApplicationZero-Speed and General Splicing
Primary Liner Thickness (Imperial) UOMmil
Carrier Thickness1.0
Face Side Adhesive Thickness (Metric)0.04
Volume (Imperial) UOMfl
Maximum Operating Temperature (Fahrenheit) UOMDegree
Shelf Life UOMMonth
Carrier Thickness (Metric) UOMmm
Back Side Adhesive Thickness (Imperial) UOMmil
Carrier Thickness (Metric)0.03
Primary Liner60# Densified Kraft Paper
Minimum Operating Temperature (Fahrenheit) UOMDegree
Physical FormLiquid
Backing (Carrier) Thickness (Imperial)1.0
Overall Length (Metric)54.86
Overall Thickness (Imperial)4.0
Primary Liner Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Imperial)1.5
Primary Liner Thickness (Imperial)4.0
Back Side Adhesive Thickness (Imperial)1.5
Product TypeInstant Adhesive
Back Side Adhesive Thickness (Metric) UOMmm
Adhesive TypeCyanoacrylate
Overall Width (Metric) UOMmm
Product ColorTransparent
Overall Length (Imperial)60.0
Primary Liner ColorTan
Master Size Width (Metric) UOMcm
Set Time12 to 60 Second
Overall Width (Metric)609.6
Volume (Imperial)1.0
Backing (Carrier) Thickness (Metric)0.025
