3M Products & Supplies

3M™ Double Coated Tape 9576, Clear, 1 in x 60 yd, 4 mil, 36 Roll/Case - 7000123453

Sold As: 36-Pack
SKU: 7000123453
MPN: 7000123453
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00021200842665
3M ID: 70006128253
5 Digit UPC: 84266
$708.76 ($19.69 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9576 is a medium tack tape for general splicing and roll closing applications. This tape offers ultra-high peel strength and excellent shear strength for durability. It is conformable to irregular surfaces and offers excellent UV and heat resistance.

Features

  • Double sided adhesion increases dimensional stability for easy handling
  • Conformable to irregular surfaces
  • Excellent peel and shear strength to withstand rigorous splicing applications
  • Bonds well to most substrates, including low surface energy plastics
  • Medium tack double coated tape for roll-to-roll splicing, core starting and roll closing
  • Excellent UV and heat resistance
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Set Time12 to 60 Second
Tape TypeSingle Coated
Primary Liner Thickness (Imperial)4.0
Shelf Life in Months (From Date of Manufacture) UOMMonths
Backing (Carrier) MaterialPolypropylene
Carrier Thickness (Metric)0.03
Backing (Carrier) Thickness (Imperial) UOMmil
Primary Liner60# Densified Kraft Paper
Master Size Length (Metric)329.2
Overall Width (Metric)25.4
Carrier Thickness1.0
Back Side Adhesive Thickness (Imperial)1.5
Master Size Length (Imperial)360.0
Primary Liner Thickness (Metric)0.1
Backing (Carrier) Thickness (Metric)0.025
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Imperial) UOMmil
Master Size Width (Metric) UOMcm
Master Size Width (Imperial) UOMin
Overall Length (Metric) UOMm
Primary Liner Thickness (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial) UOMyd
Product FormRoll
Total Tape Thickness without Liner (Metric)0.1
Overall Length (Metric)54.86
Units per Case36.0
ApplicationZero-Speed and General Splicing
Backing (Carrier) Thickness (Metric) UOMmm
Overall Length (Imperial)60.0
Maximum Operating Temperature (Fahrenheit)165.0
Overall Thickness (Imperial) UOMmil
Carrier Thickness (Metric) UOMmm
Carrier MaterialPolypropylene
Face Side Adhesive Thickness (Metric) UOMmm
Back Side Adhesive Thickness (Imperial) UOMmil
Shelf Life in Months (From Date of Manufacture)9.0
Master Size Length (Metric) UOMm
Maximum Operating Temperature (Celsius)50.0
Overall Width (Metric) UOMmm
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Thickness (Imperial)4.0
Shelf Life UOMMonth
Product ColorTransparent
Total Tape Thickness without Liner (Imperial)4.0
Face Side Adhesive TypeHigh Tack Acrylic 400
Overall Width (Imperial)1.0
IndustriesGeneral Industrial, Paper, Print
Back Side Adhesive Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Imperial)1.0
Carrier Thickness UOMmil
Face Side Adhesive Thickness (Imperial)1.5
Face Side Adhesive Thickness (Metric)0.04
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit)-40.0
Master Size Width (Metric)69.0
Master Size Width (Imperial)27.0
Primary Liner ColorTan
Master Size Length (Imperial) UOMLinear
