3M Products & Supplies

3M™ Double Coated Tape 9629B, Black, 54 in x 60 yd, 4 mil, 1 Roll/Case - 7100269605

Sold As: 3-Pack
SKU: 7100269605
MPN: 7100269605
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060001634
3M ID: 70007549226
5 Digit UPC: 163
$4,801.35 ($1600.45 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9629B provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The black polyester (PET) carrier adds dimensional stability to substrates and makes it easier to handle during converting and application.

Features

  • Provides high bond strength to dissimilar materials such as metals and most plastics
  • Natural 60# glassine release liner
  • 3M™ Adhesive 360 delivers very high initial bond strength
  • Excellent adhesion to difficult to bond to surfaces such as PP, HDPE and LDPE
  • Black polyester carrier adds dimensional stability and improved handling
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Imperial) UOMin
IndustriesElectronics, General Industrial
Overall Width (Imperial)54.0
Overall Length (Imperial)60.0
Overall Length (Imperial) UOMyd
Back Side Adhesive Thickness (Metric)0.04
Overall Width (Metric) UOMmm
Overall Width (Metric)1371.6
Backing (Carrier) Thickness (Imperial)0.5
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.1
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Length (Metric)54.864
Adhesive TypeQuick Bond Acrylic Adhesive 360
Backing (Carrier) MaterialPET
Backing (Carrier) Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.013
Face Side Adhesive Thickness (Imperial)1.75
Total Tape Thickness without Liner (Imperial)4.0
Total Tape Thickness without Liner (Imperial) UOMmil
Product ColorBlack
Back Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Length (Metric) UOMm
Back Side Adhesive Thickness (Imperial)1.75
Face Side Adhesive Thickness (Metric) UOMmm
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Back Side Adhesive Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Metric)0.04
