3M Products & Supplies

3M™ Double Coated Tape 9629B, Black, 54 in x 60 yd, 4 mil, 1 Roll/Case - 7100042532

SKU: 7100042532
MPN: 7100042532
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007995050
3M ID: 70006818879
5 Digit UPC: 99505
$1,696.48 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9629B provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The black polyester (PET) carrier adds dimensional stability to substrates and makes it easier to handle during converting and application.

Features

  • Natural 60# glassine release liner
  • Excellent adhesion to difficult to bond to surfaces such as PP, HDPE and LDPE
  • Provides high bond strength to dissimilar materials such as metals and most plastics
  • Black polyester carrier adds dimensional stability and improved handling
  • 3M™ Adhesive 360 delivers very high initial bond strength
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Celsius) UOMDegree
Face Side Adhesive Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Metric) UOMmm
Minimum Operating Temperature (Celsius)-40.0
Maximum Operating Temperature (Celsius)93.0
Overall Width (Imperial) UOMin
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Overall Length (Imperial) UOMyd
Overall Width (Metric)1371.6
Backing (Carrier) Thickness (Metric)0.013
Back Side Adhesive Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Metric)0.04
Overall Length (Metric) UOMm
IndustriesElectronics, General Industrial
Product ColorBlack
Overall Length (Metric)54.864
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) MaterialPET
Face Side Adhesive Thickness (Imperial)1.75
Backing (Carrier) Thickness (Metric) UOMmm
Adhesive TypeQuick Bond Acrylic Adhesive 360
Primary Liner Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)4.0
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Imperial)54.0
Back Side Adhesive Thickness (Metric)0.04
Backing (Carrier) Thickness (Imperial)0.5
Overall Length (Imperial)60.0
Total Tape Thickness without Liner (Metric)0.1
Back Side Adhesive Thickness (Imperial)1.75
Minimum Operating Temperature (Celsius) UOMDegree
Primary Liner Thickness (Imperial)3.2
