3M Products & Supplies

3M™ Double Coated Tape 9731, Clear, 38 in x 108 yd, 5.5 mil, 1 Roll/Case - 7000049118

SKU: 7000049118
MPN: 7000049118
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138955687
3M ID: 70006389855
5 Digit UPC: 95568
$16,991.59 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9731 was developed with a high-performance acrylic adhesive on the face side and a silicone adhesive on the liner side of a 1 mil clear PET carrier. It is excellent for demanding applications where silicone materials must be bonded to a range of substrates.

Features

  • Ideal for attaching silicone rubber elastomers and foam
  • Features acrylic and silicone adhesives for specialized applications such as silicone gasketing
  • 3 mil silicone adhesive on liner side bonds well to silicone substrates
  • 3M™ Adhesive 350 on the face side provides exceptional temperature and chemical resistance
  • Double linered – Adhesive 350 on 58# 4.2 mil PCK liner and silicone adhesive on 3 mil PET liner
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Carrier Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Shelf Life UOMMonth
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner ColorTan
Tape TypeDouble Coated
Total Tape Thickness without Liner (Metric)0.14
Assembly TypeGasket Attachment
Primary Liner Thickness (Metric)0.17
Product ColorTransparent
Overall Length (Metric)98.75
Back Side Adhesive TypeSilicone
Overall Thickness (Imperial) UOMmil
Carrier Thickness UOMmil
Maximum Operating Temperature (Celsius)121.0
Secondary Liner Thickness (Metric)0.07
Backing (Carrier) Thickness (Metric)0.025
Back Side Adhesive Thickness (Imperial) UOMmil
Core Size (Imperial)3.0
Secondary Liner Thickness (Imperial) UOMmil
IndustriesAerospace, Appliance, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Metalworking, Military and Government, Oil & Gas, Signage, Specialty Vehicles, Transportation
Shelf Life in Months (From Date of Manufacture) UOMMonths
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Core Size (Metric) UOMmm
Primary Liner58# Polycoated Kraft Paper (PCK)
Face Side Adhesive Thickness (Imperial)1.6
Overall Width (Imperial)38.0
Total Tape Thickness without Liner (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)250.0
Face Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric) UOMm
Overall Length (Imperial)108.0
Primary Liner Thickness (Imperial)4.2
Back Side Adhesive Thickness (Metric) UOMmm
Minimum Operating Temperature (Celsius)-40.0
Master Size Length (Metric)98.8
Carrier MaterialPolyester Film
Primary Liner Thickness (Metric) UOMmm
Secondary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)5.5
Face Side Adhesive Thickness (Metric)0.041
Minimum Operating Temperature (Fahrenheit)-40.0
Backing (Carrier) Thickness (Imperial)1.0
Secondary Liner Thickness (Imperial)2.9
Master Size Width (Metric) UOMcm
Master Size Width (Metric)122.0
Core Size (Metric)76.2
Face Side Adhesive TypeHigh Performance Acrylic Adhesive 350
Overall Thickness (Imperial)5.5
Core Size (Imperial) UOMin
Face Side Adhesive Thickness (Imperial) UOMmil
Units per Case1.0
Shelf Life in Months (From Date of Manufacture)12.0
Backing (Carrier) MaterialPolyester Film
Overall Width (Metric)965.2
Total Tape Thickness without Liner (Imperial) UOMmil
Product FormRoll
Indoor/OutdoorBoth
Minimum Operating Temperature (Celsius) UOMDegree
Carrier Thickness0.0951388888888889
Primary Liner Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Imperial)2.9
Overall Width (Imperial) UOMin
Master Size Length (Metric) UOMm
Carrier Thickness (Metric)0.03
Backing (Carrier) Thickness (Imperial) UOMmil
