3M Products & Supplies

3M™ XYZ-Axis Electrically Conductive Tape 9713, 12 in x 108 yds, 1/Case - 7000048868

Sold As: 2-Pack
SKU: 7000048868
MPN: 7000048868
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200432125
3M ID: 70006280138
5 Digit UPC: 43212
$8,847.60 ($4423.80 / Count)
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Adhesive Transfer Tape 9713 is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. This double-sided tape has a conductive nickel-coated carbon fiber scrim carrier. It has a good balance of adhesion and conductivity, which is optimal for larger contact areas where high electrical conductivity is not required. This electrically conductive tape can be die cut and offers excellent workability and easy handling. It provides robust protection against EMI in a range of market segments, including consumer electronics, automotive, medical equipment, communications infrastructure, and aerospace and defense electronics.

Features

  • Excellent die-cutting and converting capabilities
  • Thinner adhesive than 3M™ XYZ-Axis Electrically Conductive Tape 9712
  • Good contact with both hard and soft surfaces
  • Isotropic XYZ-axis electrical conductivity
  • Can be applied in strips or die cut to specific shapes and sizes
  • Nickel-plated carbon fiber scrim (a more conductive scrim)
Spec Sheet



Downloads

Specifications

Shelf Life24.0 Month
Country of OriginUnited States
Electrical ResistanceZ-axis 1.7 Ω, XY-axis 5 Ω
Overall Width (Imperial)12.0
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)3.5
Total Tape Thickness without Liner (Metric)0.089
Product UsageBond Line Gaps; Chassis; EMI Gaskets; EMI Shields; Flexible Printed Circuits; Printed Circuit Boards; Sensors
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Overall Length (Metric)98.755
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting
Overall Width (Metric) UOMmm
Overall Length (Metric) UOMm
Overall Length (Imperial)108.0
Product ColorGray
Overall Width (Metric)304.8
Backing (Carrier) MaterialNon-woven
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Liner MaterialPET
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Overall Length (Imperial) UOMyd
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Adhesive TypeAcrylic
Adhesion Strength (Imperial)1500.0
