3M Products & Supplies

3M™ Electrically Conductive Double-Sided Tape 5113DFT-50, 1080 mm x 120 m, 1 Roll/Case, Untrimmed - 7100311679

SKU: 7100311679
MPN: 7100311679
For an accurate lead time please contact us
UPC: 06912504327412
3M ID: XP003846860
$9,051.91 each
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double-Sided Tape 5113DFT is an electrically conductive double-sided fabric tape (DFT) that provides high adhesion, low electrical resistance, long shelf life, resistance to high temperature and humidity and excellent grounding and shielding performance. It features a proprietary polyolefin XYZ-axis conductive pressure sensitive adhesive (CPSA) and a conductive matrix carrier (a nickel/copper/nickel-coated conductive woven carrier). This grounding tape provides excellent adhesion to a variety of substrates including metals and plastics and helps control signal interference through passive intermodulation (PIM) mitigation for higher signal integrity and performance. This double-sided fabric tape helps protect against EMI in a range of market segments, including general industrial electronics, aerospace and defense electronics, appliances, automotive electronics and IoT devices, communications infrastructure, and medical equipment.

Features

  • Four-year shelf life for reliable, consistent performance over time
  • Excellent grounding with small contact areas for microelectronics
  • Excellent EMI shielding performance for a wide range of frequencies
  • Excellent EMI shielding in bond line gap
  • Isotropic XYZ-axis conductivity through the adhesive
  • Long-term performance at high temperatures (105 ˚C) for demanding applications
Spec Sheet



Downloads

Specifications

Shelf Life48.0 Month
Country of OriginChina
Overall Length (Metric)120.0
Adhesion Strength (Imperial)1500.0
Overall Width (Imperial)42.52
Overall Width (Metric)1080.0
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Metric)0.05
Total Tape Thickness without Liner (Imperial)2.0
Overall Width (Metric) UOMmm
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Overall Length (Imperial)131.234
Adhesive TypePolyolefin
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting; Passive Intermodulation (PIM) Management
Overall Width (Imperial) UOMin
Overall Length (Imperial) UOMyd
Backing (Carrier) MaterialWoven Fabric
Electrical ResistanceXY-axis 0.01 Ω, Z-axis 0.03 Ω
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Liner MaterialPET
Overall Length (Metric) UOMm
Product ColorGray
Product UsageBond Line Gaps; Chassis; EMI Gaskets; EMI Shields; Flexible Printed Circuits; Printed Circuit Boards; Sensors
