3M Products & Supplies

3M™ Embossed Aluminum Foil EMI Shielding Tape 1267, 7.7 in x 10 in, Sheet, 10 Sheets/Bag - 7010305700

Sold As: 10-Pack
SKU: 7010305700
MPN: 7010305700
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128558133
3M ID: 80611420367
5 Digit UPC: 55813
$156.50 ($15.65 / Count)
Hurry up! Current stock:

Product Description

3M™ Embossed Aluminum EMI Shielding Tape 1267 is an acrylic adhesive EMI shielding tape. This flame retardant tape is designed for applications that require outstanding electrical conductivity. It comes on a liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Removable liner for easy die-cutting and handling
  • Offers outstanding contact through the adhesive with an embossed pattern
  • Flame-retardant
  • UL Listed and RoHS 2011/65/EU Compliant
  • Embossed backing cuts through the layer of adhesive for establishing contact between the backing and the application substrate
  • Rated for 600V applications

Specifications

Shelf Life1825
Country of OriginTaiwan
Backing MaterialAluminum; Aluminum Foil; Embossed Aluminum Foil
Maximum Operating Temperature (Celsius)130.0
Shelf Life UOMYear
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Metric) UOMmm
Overall Width (Imperial) UOMin
Tensile Strength (Imperial) UOMlb/in
Overall Width (Imperial)7.7
Primary LinerPaper
Total Tape Thickness without Liner (Imperial)5.0
Overall Width (Metric)195.58
Maximum Operating Temperature (Celsius) UOMDegree
Shielding Effectiveness80.0
Tensile Strength (Metric)35.0
Adhesive TypeAcrylic
Elongation at Break100
Specifications MetRoHS 2011/65/EU, UL Recognized
IndustriesElectronics
Product MarketsElectrical Equipment Manufacturing
Tensile Strength (Imperial)20.0
ApplicationShielding
Tensile Strength (Metric) UOMN/10mm
