3M Products & Supplies

3M™ Embossed Tin-Plated Copper Foil EMI Shielding Tape 1345, 7.7 in x 10 in, Sheet, 10 Sheets/Bag - 7100050828

Sold As: 10-Pack
SKU: 7100050828
MPN: 7100050828
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128558140
3M ID: 80611420375
5 Digit UPC: 55814
$105.11 ($10.51 / Count)
Hurry up! Current stock:

Product Description

3M™ Embossed Tin Plated Copper EMI Shielding Tape 1345 is an EMI shielding tape with an acrylic adhesive. This flame retardant tape is designed for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Embossed, copper foil backing resists discoloration and oxidation
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Flame-retardant and suitable for grounding and EMI shielding in equipment, components and shielded rooms
  • Offers stable contact resistance and good shielding effectiveness
  • Embossed backing cuts through the layer of adhesive for establishing contact between the backing and the application substrate
  • Offers outstanding solderability with tin-plated coating

Specifications

Shelf Life1825
Country of OriginTaiwan
Overall Width (Imperial)7.7
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Metric)0.035
Tensile Strength (Metric) UOMN/cm
Backing (Carrier) MaterialTin Plate Copper Foil, Embossed
Total Tape Thickness without Liner (Metric)0.1016
Backing (Carrier) Thickness (Imperial) UOMmil
Maximum Operating Temperature (Celsius)130.0
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Metric)195.6
Specifications MetRoHS 2011/65/EU, UL 510, UL Listed, UL Recognized
Tape GradeProfessional
Overall Width (Metric) UOMmm
ApplicationShielding
Elongation at Break100
MaterialEmbossed Tin Plated Copper Foil
Total Tape Thickness without Liner (Metric) UOMmm
Adhesive TypeAcrylic
Backing (Carrier) Thickness (Imperial)1.4
Tensile Strength (Metric)44.0
Product MarketsElectrical Equipment Manufacturing
Product ColorTin
Shelf Life UOMYear
Maximum Operating Temperature (Celsius) UOMDegree
