3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 7.7 in x 10 in, Sheet, 10 Sheets/Case - 7100050422

Sold As: 10-Pack
SKU: 7100050422
MPN: 7100050422
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128558102
3M ID: 80611420334
5 Digit UPC: 55810
$109.61 ($10.96 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Rated for 600V applications
  • Flame-retardant
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Comes on a removable liner for easy die-cutting and handling
  • Unique adhesive creates secure contact with the application surface
  • Suitable for grounding and EMI shielding equipment, components and shielded rooms

Specifications

Shelf Life1825
Country of OriginTaiwan
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric)0.035
Overall Width (Metric)195.6
Product ColorTin
Tensile Strength (Metric) UOMN/cm
Product MarketsElectrical Equipment Manufacturing
Backing (Carrier) Thickness (Imperial)1.4
Tape GradeProfessional
Tensile Strength (Metric)44.0
Overall Width (Imperial)7.7
Overall Width (Imperial) UOMin
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
Total Tape Thickness without Liner (Metric) UOMmm
MaterialTin Plated Copper Foil
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Adhesive TypeConductive Acrylic
ApplicationShielding
Total Tape Thickness without Liner (Metric)0.066
Shelf Life UOMYear
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
