3M™ Heat Shrink Flexible Polyolefin Tubing EPS200-3/8-48"-Black-125 Pcs, 48 in length sticks, 125 pieces, 125/Case - 7000133599

Sold As: 125-Pack
SKU: 7000133599
MPN: 7000133599
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128598160
3M ID: 80611600778
5 Digit UPC: 59816
$956.20 ($7.65 / Count)
Hurry up! Current stock:

Product Description

3M™ EPS 200 Heat Shrink Tubing is a dual wall tubing that provides the advantage of integral, adhesive lined construction. This flame retardant tubing with a 2:1 shrink ratio, offers insulation for 600V rated applications. The flexible polyolefin construction with an internal layer of thermoplastic adhesive offers moisture seal protection in automotive and marine applications.

Features

  • Flame-retardant tubing is rated for 600V applications
  • Offers the advantage of integral, adhesive-lined construction
  • Dual-wall construction provides abrasion resistance and moisture-seal protection
  • Made of black flexible polyolefin
  • Protects electronic components, automotive, truck and marine wiring splices or bundling of wires
  • Withstands temperatures of -67 to 230 degrees F (-55 to 110 degrees C)

Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Minimum Expanded Tubing I. D.0.375
Inner Diameter After Shrink (Imperial)0.187
Shrink Ratio2:1
Units per Case125.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Flame RetardantYes
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Inner Diameter Before Shrink (Metric) UOMmm
Non-CorrosiveYes
Inner Diameter Before Shrink (Metric)9.53
Inner Diameter After Shrink (Metric)4.75
Maximum Operating Temperature (Fahrenheit)275.0
Inner Diameter After Shrink (Imperial) UOMin
Inner Diameter After Shrink (Metric) UOMmm
Inner Diameter Before Shrink (Imperial)0.375
Overall Length (Imperial)48.0
UL File NumberE-39100
Elongation UOM%
Inner Diameter Before Shrink (Imperial) UOMin
MaterialPolyolefin
Overall Length (Imperial) UOMin
Mil SpecAMS-DTL-23053/4, Class 2
Maximum Operating Temperature (Celsius)110.0
Minimum Expanded Tubing I. D. UOMin
Maximum Operating Temperature (Celsius) UomDegree
