3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-3/8-48"-Black-125 Pcs, 48 in Length sticks, 125 pieces/case - 7100086437

Sold As: 125-Pack
SKU: 7100086437
MPN: 7100086437
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128598375
3M ID: 80611600984
5 Digit UPC: 59837
$315.66 ($2.53 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Inner Diameter Before Shrink (Metric) UOMmm
Product ColorBlack
Units per Case125.0
Maximum Operating Temperature (Celsius) UomDegree
Overall Length (Imperial)48.0
UL Bug Temperature (Celsius)125 Degrees Celsius
Flame RetardantYes
Inner Diameter After Shrink (Imperial) UOMin
Inner Diameter Before Shrink (Imperial)0.375
Inner Diameter After Shrink (Metric) UOMmm
Minimum Expanded Tubing I. D.3.0
UL Bug Voltage600 Volt
Mil SpecAMS-DTL-23053/5, Class 1
Minimum Expanded Tubing I. D. UOMin
Non-CorrosiveYes
Inner Diameter After Shrink (Imperial)0.187
Adhesive MaterialNone
Overall Length (Metric)1220.0
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Maximum Operating Temperature (Fahrenheit)275.0
Operating Temperature (Fahrenheit)-67 °F to 275 °F
Overall Width (Metric)9.52
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
Inner Diameter Before Shrink (Metric)9.53
Operating Temperature Range (Fahrenheit)-67 °F to 275 °F
UL ApprovalYes
Minimum Shrink Temperature (Celsius)100.0
Operating Temperature Range (Celsius)-55 °C to +135 °C
Overall Width (Imperial)0.37
Elongation UOM%
Overall Width (Imperial) UOMin
Tubing TypeSingle Wall (Thin)
Maximum Operating Temperature (Fahrenheit) UOMDegree
Shrink Ratio2:1
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Celsius)135.0
MaterialPolyolefin
Overall Length (Imperial) UOMin
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Inner Diameter Before Shrink (Imperial) UOMin
Inner Diameter After Shrink (Metric)4.75
UL Bug Temperature (Fahrenheit)257 Degrees Fahrenheit
Overall Length (Metric) UOMmm
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
