3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-3/16-48"-Black-Hdr-25 Pcs, 48 in Length sticks with header label, 25 pieces/case - 7000133546

Sold As: 25-Pack
SKU: 7000133546
MPN: 7000133546
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128596470
3M ID: 80611473085
5 Digit UPC: 59647
$88.26 ($3.53 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Adhesive MaterialNone
Mil SpecSAE-AMS-DTL-23053/5, Class 1
UL File NumberE-39100
Minimum Expanded Tubing I. D.0.187
Operating Temperature Range (Celsius)-55 °C to +135 °C
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius)135.0
Tubing TypeSingle Wall (Thin)
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Inner Diameter After Shrink (Imperial) UOMin
Inner Diameter After Shrink (Metric) UOMmm
Flame RetardantYes
Units per Case25.0
Operating Temperature (Fahrenheit)-67 °F to 275 °F
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
MaterialPolyolefin
UL Bug Voltage600 Volt
Overall Length (Metric) UOMmm
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Fahrenheit)275.0
Overall Length (Imperial) UOMin
Overall Length (Metric)1220.0
Operating Temperature Range (Fahrenheit)-67 °F to 275 °F
Inner Diameter Before Shrink (Metric) UOMmm
Minimum Expanded Tubing I. D. UOMin
Product ColorBlack
UL ApprovalYes
Inner Diameter After Shrink (Metric)2.36
Non-CorrosiveYes
Minimum Shrink Temperature (Celsius)100.0
Inner Diameter After Shrink (Imperial)0.093
Elongation UOMdB
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter Before Shrink (Metric)4.75
Inner Diameter Before Shrink (Imperial)0.187
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
Shrink Ratio2:1
UL Bug Temperature (Celsius)125 Degrees Celsius
UL Bug Temperature (Fahrenheit)257 Degrees Fahrenheit
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Inner Diameter Before Shrink (Imperial) UOMin
Overall Width (Imperial)0.19
Overall Length (Imperial)48.0
