3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-3/64-Blue-1000`: 1000 ft spool length, 3000 linear ft/case - 7010396628

Sold As: 3000-Pack
SKU: 7010396628
MPN: 7010396628
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 10054007586132
3M ID: 80610675714
5 Digit UPC: 58613
$1,245.55 ($0.42 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Inner Diameter Before Shrink (Imperial) UOMin
Inner Diameter After Shrink (Imperial)0.023
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Product ColorBlue
Maximum Operating Temperature (Celsius)135.0
UL File NumberE-39100
Overall Length (Imperial)1000.0
Inner Diameter After Shrink (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Inner Diameter Before Shrink (Imperial)0.046
Inner Diameter Before Shrink (Metric) UOMmm
Minimum Expanded Tubing I. D. UOMin
Tubing TypeSingle (Thin) Wall
Minimum Expanded Tubing I. D.3.0
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Non-CorrosiveYes
Overall Length (Imperial) UOMft
Adhesive MaterialNone
Shrink Ratio2:1
Elongation UOM%
Inner Diameter After Shrink (Imperial) UOMin
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter Before Shrink (Metric)1.17
Maximum Operating Temperature (Fahrenheit)275.0
Inner Diameter After Shrink (Metric)0.58
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
Mil SpecAMS-DTL-23053/5, Class 1
Flame RetardantYes
