3M™ Highland™ Nylon Fully Insulated Female Disconnect Terminal FDI14-250Q, AWG 16-14, 25/bag, 10 Bags/Case - 7000133658

Sold As: 10-Pack
SKU: 7000133658
MPN: 7000133658
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128600016
3M ID: 80611602626
5 Digit UPC: 60001
$86.61 ($8.66 / Count)
Hurry up! Current stock:

Product Description

3M™ Highland™ Color-Coded Female Disconnect Terminal has dents and rolled edges to offer superior holding force while allowing for quick and easy disconnect. The terminal has a fully insulated, nylon, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Nylon-insulated, butted-seam barrel offers easy insertion of wires
  • Allows for quick and easy disconnect of wires
  • Dents and rolled edges of this female disconnect terminal offer excellent holding force
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Width (Imperial) UOMin
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Terminal TypeDisconnect
Barrel Inside Diameter0.08 Inch
Connection Width (Metric) UOMmm
Maximum Insulation Outer Diameter (Metric)3.7
Overall Width (Metric)9.4
Overall Diameter (Imperial)0.23
Insulation MaterialNylon
Diameter (D)0.23 Inch
Fastener OrientationFemale
Maximum Recommended Voltage Rating UOMV
Connection Width (Imperial)0.25
Maximum Insulation Outer Diameter (Metric) UOMmm
Barrel Length (Metric)6.35 mm
Mates with Female Width0.25 Inch
Units per bag25
Conductor Sizes (Imperial)16 - 14 AWG
Maximum Insulation Outer Diameter (Imperial) UOMin
Maximum Insulation Outer Diameter (Imperial)0.145
Overall Width (Imperial)0.37
Maximum Insulation Outside Diameter0.145 in
Maximum Conductor Size (Imperial)14 AWG
Max. Number of Cores413.0
Overall Length (Imperial) UOMin
Disconnect TypeFemale
Overall Diameter (Metric) UOMmm
Minimum Conductor Size (Imperial)16 AWG
Overall Width (Metric) UOMmm
Units per Case10.0
Mates with Male Tab Width (W')0.25 Inch
Connection Width (Metric)6.35
Barrel StyleButted
UL File NumberE70512
Overall Length (Metric) UOMmm
Maximum Recommended Voltage Rating600.0
Overall Length (Imperial)0.87
Connection Width (Imperial) UOMin
Maximum Conductor Size (Metric)2.5 mm²
Tab Width0.250
Pad Width0.25
MaterialPlastic
Terminal StyleFully Insulated
Minimum Conductor Size (Metric)1.5 mm²
Barrel Length (Imperial)0.25 Inch
Packaging25 per bag
Overall Length (Metric)22.098
Maximum Voltage Rating600 to 1000 V
Overall Diameter (Imperial) UOMin
Overall Diameter (Metric)5.84
