3M™ Non-Insulated Brazed Seam Ring Tongue Terminal 13-14S-W, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163686

Sold As: 1000-Pack
SKU: 7100163686
MPN: 7100163686
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007287391
3M ID: 80601384540
MPN: 13-14S-W
$185.04 ($0.19 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Standard-style ring tongue fits around the stud

Downloads

Specifications

Insulation MaterialNon-insulated
Barrel StyleBrazed
Minimum Conductor Size (Imperial)12 AWG
Ring TypeStandard
UL File NumberE23438
Connection TypeCrimp
Minimum Conductor Size (Metric)3.31 mm²
Terminal TypeRing
Terminal StyleStandard
Maximum Operating Temperature (Celsius)175.0
Barrel Length (Imperial)0.25 Inch
Maximum Conductor Size (Imperial)10 AWG
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Conductor Size (Metric)5.26
Minimum Stud Diameter (Metric)6.35
Minimum Stud Diameter (Imperial) UOMin
Minimum Stud Diameter (Metric) UOMmm
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Country of OriginUnited States
