3M™ Nylon Insulated Brazed Seam Ring Tongue Terminal, 15-38-WN, standard-style ring tongue fits around the stud - 7100164220

Sold As: 1000-Pack
SKU: 7100164220
MPN: 7100164220
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007082484
3M ID: 80610154058
MPN: 15-38-WN
$674.24 ($0.67 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Standard-style ring tongue fits around the stud
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)

Downloads

Specifications

Maximum Conductor Size (Metric)13.3
UL File NumberE23438
Terminal TypeRing
Maximum Operating Temperature (Celsius) UOMDegree
Insulation MaterialNylon
Terminal StyleStandard
Minimum Stud Diameter (Metric)9.525
Barrel StyleBrazed
Minimum Stud Diameter (Imperial) UOMin
Ring TypeStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Conductor Size (Imperial)6 AWG
Maximum Conductor Size (Imperial)6 AWG
Minimum Conductor Size (Metric)13.3 mm²
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric) UOMmm
Barrel Length (Imperial)0.25 Inch
Connection TypeCrimp
Country of OriginUnited States
