3M™ Nylon Insulated Brazed Seam Ring Tongue Terminal, 16-38-WN, standard-style ring tongue fits around the stud - 7100164225

Sold As: 1000-Pack
SKU: 7100164225
MPN: 7100164225
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007082583
3M ID: 80610154157
MPN: 16-38-WN
$1,048.82 ($1.05 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud

Downloads

Specifications

UL File NumberE23438
Terminal StyleStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Conductor Size (Imperial)4 AWG
Maximum Conductor Size (Metric)21.2
Terminal TypeRing
Minimum Conductor Size (Imperial)4 AWG
Minimum Stud Diameter (Metric)9.525
Minimum Stud Diameter (Metric) UOMmm
Country of OriginUnited States
Ring TypeStandard
Minimum Stud Diameter (Imperial) UOMin
Connection TypeCrimp
Barrel StyleBrazed
Barrel Length (Imperial)0.25 Inch
Maximum Operating Temperature (Celsius)175.0
Insulation MaterialNylon
Minimum Conductor Size (Metric)21.2 mm²
