3M Products & Supplies

3M™ Nylon Insulated Brazed Seam Ring Tongue Terminal, 16-14-WN, standard-style ring tongue fits around the stud - 7100164223

Sold As: 1000-Pack
SKU: 7100164223
MPN: 7100164223
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007082569
3M ID: 80610154132
MPN: 16-14-WN
$1,048.82 ($1.05 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Downloads

Specifications

Minimum Stud Diameter (Metric) UOMmm
Terminal TypeRing
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Conductor Size (Metric)2.08
Insulation MaterialNylon
UL File NumberE23438
Connection TypeCrimp
Barrel Length (Imperial)0.25 Inch
Country of OriginUnited States
Minimum Conductor Size (Imperial)16 AWG
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Metric)1.31 mm²
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric)6.35
Barrel StyleBrazed
Ring TypeStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Stud Diameter (Imperial) UOMin
Terminal StyleStandard
