3M Products & Supplies

3M™ Performance Plus™ Wire Connector T/R+KEG, 25,000 per Keg, smooth, comfortable feel, 25000/DR - 7000132941

Sold As: 25000-Pack
SKU: 7000132941
MPN: 7000132941
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128544563
3M ID: 80611237779
5 Digit UPC: 54456
$3,970.65 ($0.16 / Count)
Hurry up! Current stock:

Product Description

3M™ Performance Plus™ Wire Connectors T/R+ are constructed to work with a wire range between 2 #18 to 5 #12 AWG. The connectors feature a uniquely flexible spring that provides ample expansion capacity and a strong, reliable grip. Their expanded cable range allows three Performance Plus™ connectors to replace eight standard connectors, improving convenience at work by using fewer parts for a larger number of wire combinations. In addition, the flexible skirt helps reduce copper exposure for enhanced reliability, and the connectors are UL Listed for 600 V on copper wire.

Features

  • Dual color coded: one connector does the job of two traditional connectors in the majority of applications
  • UL Listed
  • Strong bite for a secure, reliable connection
  • Flexible spring expands for greater wire range and reuse
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Product ColorRed
Connection TypeWire
Maximum Operating Temperature (Celsius)105.0
Maximum Operating Temperature (Celsius) UOMDegree
Product TypeConnector
Units per Case25000.0
Maximum Conductor Size (Metric)10
Minimum Operating Temperature (Fahrenheit)0.0
Minimum Conductor Size (Metric).34 mm²
Maximum Voltage Rating600 V
Maximum Conductor Size (Imperial)8 AWG
Specifications MetCSA, UL Listed
Minimum Operating Temperature (Celsius)0.0
PackagingKeg
Minimum Conductor Size (Imperial)22 AWG
Maximum Operating Temperature (Fahrenheit) UOMDegree
Flame RetardantYes
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Fahrenheit)221.0
Connector StyleTwist On
