3M Products & Supplies

3M™ Polyester Film Electrical Tape 1350F-1, Black, 1 in x 72 yd, 3-in paper core, Log roll, 12 Rolls/Case - 7010297834

Sold As: 12-Pack
SKU: 7010297834
MPN: 7010297834
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051125652643
3M ID: 80621000126
5 Digit UPC: 65264
$378.58 ($31.55 / Count)
Hurry up! Current stock:

Product Description

3M™ Polyester Film Electrical Tape 1350F-1 tape is a yellow, white, or black, UL recognized flame retardant, 2.5-mil (0.064 mm) thick tape composed of a 1-mil (0.025 mm) polyester film backing coated on one side with a non-corrosive, acrylic pressure-sensitive adhesive.

Features

  • Nominal thickness: 0.064 mm (2.5 mil)
  • 5 year shelf-life when stored per 3M recommended conditions
  • UL Recognized and CSA certified 130°C temperature rating
  • Printable
  • UL Recognized flame retardant
  • Pressure-sensitive acrylic adhesive with polyester film backing
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginTaiwan
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial)1.0
Backing (Carrier) MaterialPolyester
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius)130.0
Minimum Operating Temperature (Celsius)0.0
Adhesive TypeAcrylic
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)2.5
Minimum Operating Temperature (Celsius) UOMDegree
Total Tape Thickness without Liner (Metric) UOMmm
Tape GradeProfessional
Overall Width (Metric) UOMmm
Product MarketsElectrical Equipment Manufacturing
Product ColorBlack
Overall Width (Metric)25.4
Electrolytic Corrosion Factor1.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Fahrenheit)32.0
Total Tape Thickness without Liner (Metric)0.064
Specifications MetRoHS 2011/65/EU, UL 510, UL Listed
ApplicationInsulation
Maximum Operating Temperature (Fahrenheit)266.0
Shelf Life UOMYear
Maximum Operating Temperature (Celsius) UOMDegree
