3M Products & Supplies

3M™ Polyester Film Electrical Tape 58, 1/2 in X 72 yd, Clear, 72 Rolls/Case - 7010045323

Sold As: 72-Pack
SKU: 7010045323
MPN: 7010045323
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128567494
3M ID: 80611433378
5 Digit UPC: 56749
$1,799.48 ($24.99 / Count)
Hurry up! Current stock:

Product Description

3M™ Electrical Tape 58 is a general purpose, polyester film tape that has a thermosetting, rubber adhesive which provides excellent adherence. This high temperature tape offers excellent resistance to chemicals, solvents, moisture, abrasion and cu through. RoHS 2011/65/EU Compliant .

Features

  • UL Recognized Class 130°C/CSA
  • UL Recognized flame retardant
  • Printable
  • Excellent Flagging Resistant
  • Excellent shelf life
  • Solvent resistant without thermosetting
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginMexico
Overall Length (Metric)65.8
Adhesive TypeThermosetting Rubber
Minimum Operating Temperature (Celsius)0.0
Overall Length (Metric) UOMm
Maximum Operating Temperature (Celsius)130.0
Insulation Resistance1 x 10^6 megohms
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Metric)12.7
Overall Length (Imperial)72.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Electrolytic Corrosion Factor1.0
Minimum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial)0.5
Overall Width (Imperial) UOMin
Rolls per Case72.0
Shelf Life UOMYear
Overall Width (Metric) UOMmm
Overall Length (Imperial) UOMyd
Maximum Operating Temperature (Celsius) UOMDegree
Specifications MetRoHS 2011/65/EU, UL 510, UL Listed, UL Recognized
Maximum Operating Temperature (Fahrenheit)266.0
Backing (Carrier) MaterialPolyester
Product MarketsElectrical Equipment Manufacturing
Elongation at Break110
Dielectric Strength UOMV
Dielectric Strength7000.0
Minimum Operating Temperature (Fahrenheit)32.0
