3M Products & Supplies

3M™ Polyester Film Electrical Tape 75, Yellow, 1/4 in x 36 yd (6,35mm x 33m), 144/Case - 7100200854

Sold As: 144-Pack
SKU: 7100200854
MPN: 7100200854
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128567517
3M ID: 80611433394
5 Digit UPC: 56751
$1,867.44 ($12.97 / Count)
Hurry up! Current stock:

Product Description

3M™ Polyester Film Electrical Tape 75 is a double coated polyester film electrical tape for use in bonding applications requiring a positive insulation barrier.

Features

  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Offers the advantage of integral, adhesive-lined construction
  • Flame-retardant tubing is rated for 600V applications
  • Made of semi-rigid polyolefin

Downloads

Specifications

Shelf Life4380
Country of OriginUnited States
Minimum Operating Temperature (Celsius)0.0
Overall Length (Imperial)36.0
Overall Length (Metric)33.0
Dielectric Strength UOMV
Total Tape Thickness without Liner (Imperial)3.5
Insulation Resistance1 x 10^6 megohms
Overall Width (Imperial) UOMin
Overall Length (Imperial) UOMyd
Electrolytic Corrosion Factor1.0
Overall Width (Metric) UOMmm
Adhesive TypeThermosetting Rubber
Product ColorYellow
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)266.0
Specifications MetRoHS 2011/65/EU, UL 510, UL Listed, UL Recognized
Maximum Operating Temperature (Celsius)130.0
Minimum Operating Temperature (Fahrenheit)32.0
Overall Length (Metric) UOMm
Product MarketsElectrical Equipment Manufacturing
Total Tape Thickness without Liner (Metric)0.089
Shelf Life UOMYear
Elongation at Break100
Maximum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial)0.25
Overall Width (Metric)6.35
Tape GradeProfessional
Minimum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Metric) UOMmm
Dielectric Strength6500.0
Backing (Carrier) MaterialPolyester
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius) UOMDegree
