3M Products & Supplies

3M™ Polyimide Film Electrical Tape 92, 1.33 in X 36 yds Mini-Case, 3-in plastic core - 7010398893

Sold As: 6-Pack
SKU: 7010398893
MPN: 7010398893
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138511180
3M ID: 80610896906
5 Digit UPC: 51118
$772.93 ($128.82 / Count)
Hurry up! Current stock:

Product Description

3M™ Tape 92 is a high performance, electrical tape with a polyimide film backing. This tape is designed to provide thick insulation for coils, harnesses and capacitors. The flame retardant tape withstands a temperature range of 0°C to 180°C (32 to 356 °F).

Features

  • Designed for anchoring leads and terminal boards
  • Highly conformable with a pressure-sensitive, silicone adhesive
  • Withstands a temperature rating of 0°C to 180°C
  • Flame-retardant and has polyamide backing
  • UL Listed and RoHS Compliant
  • Suitable for use as wave solder masking tape in a printed circuit board assembly
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginUnited States
Backing (Carrier) MaterialPolyimide Film
Overall Length (Imperial)36.0
Overall Width (Imperial) UOMin
Product ColorAmber
Minimum Operating Temperature (Celsius) UOMDegree
Elongation at Break40%
Tensile Strength (Metric)53.0
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Celsius)180.0
Shelf Life UOMYear
Total Tape Thickness without Liner (Metric)0.07
Overall Width (Imperial)1.33
Total Tape Thickness without Liner (Imperial)2.75
Electrolytic Corrosion Factor1.0
Tensile Strength (Metric) UOMN/cm
Total Tape Thickness without Liner (Metric) UOMmm
Adhesive MaterialThermosetting Silicone
Maximum Operating Temperature (Fahrenheit)356.0
Overall Width (Metric) UOMmm
Dielectric Strength7500.0
Overall Length (Imperial) UOMyd
Minimum Operating Temperature (Celsius)-40.0
Adhesive TypeSilicone
Insulation Resistance1 x 10^6 megohms
Overall Width (Metric)33.782
Overall Length (Metric)33.0
Dielectric Strength UOMV
Maximum Operating Temperature (Fahrenheit) UOMDegree
ApplicationInsulation
Specifications MetRoHS 2011/65/EU, UL Recognized
Overall Length (Metric) UOMm
Maximum Operating Temperature (Celsius) UOMDegree
Product MarketsElectrical Equipment Manufacturing
