3M Products & Supplies

3M™ Scotchcast™ Flame-Retardant Compound 2131, Part A Pail (44.5 lb) - 7010351754

Sold As: 10-Pack
SKU: 7010351754
MPN: 7010351754
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128609170
3M ID: 80611612427
5 Digit UPC: 60917
$14,509.11 ($1450.91 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchcast™ Flame-Retardant Compound 2131 is a 2 part, flame retardant compound, useful for coating cable jackets when splicing or repairing mine and portable cables. This permanent, polyurethane, liquid type resin has a unique formulation used in rugged conditions. The high dielectric strength offers a very good electrical insulating property to the resin.

Features

  • Useful for replacing or repairing the jacket on both single and multi core power cables
  • Typical hardness (ASTM D2240) - 82 Shore A
  • Continuous temperature of 90°C (194 °F), overload temperature of 130 °C (266 °F)
  • Has 17 minute gel time at 23 °C (73 °F)
  • Flame-retardant
  • Elongates 339% longer than its original size for easy insulation or wrapping
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Container Size (Imperial)44.5 lb
Cure MethodRoom
FlexibilitySemi-flexible
Voltage1 kV
Resin MatrixUnfilled
MaterialPolyurethane
Cable Typemulti core, non shielded, polymeric insulated cable
Product TypeElectrical Resin
Voltage ApplicationLow Voltage
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Fahrenheit)194.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Mining Sector ApprovalYes
Maximum Operating Temperature (Celsius)90.0
ApplicationSealing, electrical insulation and mechanical protection
Minimum Operating Temperature (Celsius) UOMDegree
Hardness82 Shore A
Dielectric Strength (V/mil)343 V/mil
Storage Time in Months36.0
Minimum Operating Temperature (Celsius)-40.0
Elongation UOM%
Maximum Operating Temperature90ºC (194ºF) continuous; overload rating 130ºC (266ºF)
Flame RetardantYes
Voltage Rating0.6/1 kV
Maximum Operating Temperature (Celsius) UOMDegree
