3M™ Scotchcast™ Flame-Retardant Compound 2131 Part B, (21kg/46.5 lb), 1/DR - 7000058848

SKU: 7000058848
MPN: 7000058848
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128591826
3M ID: 80611468416
5 Digit UPC: 59182
$2,653.85 each
Hurry up! Current stock:

Product Description

3M™ Scotchcast™ Electrical Resin 2131 is a 2 part, flame retardant compound, useful for coating cable jackets when splicing or repairing mine and portable cables. This permanent, polyurethane, liquid type resin has a unique formulation used in rugged conditions. The high dielectric strength offers a very good electrical insulating property to the resin.

Features

  • Useful for replacing or repairing the jacket on both single and multi core power cables
  • Has 17 minute gel time at 23 °C (73 °F)
  • Continuous temperature of 90°C (194 °F), overload temperature of 130 °C (266 °F)
  • Flame-retardant
  • Elongates 339% longer than its original size for easy insulation or wrapping
  • Typical hardness (ASTM D2240) - 82 Shore A
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Units per Case1.0
FlexibilityFlexible
Dielectric Strength (V/mil)343 V/mil
Cure MethodRoom
Storage Time in Months36.0
Product ColorBlack
Resin MatrixFilled
Elongation UOM%
Minimum Operating Temperature (Celsius) UOMDegree
Voltage Rating0.6/1 kV
Minimum Operating Temperature (Celsius)-40.0
Voltage ApplicationLow Voltage
MaterialPolyurethane
Product TypeResin
Flame RetardantYes
Maximum Operating Temperature (Celsius) UOMDegree
Package Description5 gallon pail, Part B
Container Size (Imperial)46.5 lb
ApplicationSealing, electrical insulation and mechanical protection
Mining Sector ApprovalYes
Maximum Operating Temperature (Celsius)90.0
Maximum Operating Temperature90ºC (194ºF) continuous; overload rating 130ºC (266ºF)
Hardness80 Shore A
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Cable Typemulti core, non shielded, polymeric insulated cable
Voltage1 kV
Product Series2123
