3M Products & Supplies

3M™ Scotchlok™ Block Fork Vinyl Insulated, 100/bottle, MVU14-8FBX, suitable for use in a terminal block, 500/Case - 7010351315

Sold As: 100-Pack
SKU: 7010351315
MPN: 7010351315
For an accurate lead time please contact us
UPC: 00051128590331
3M ID: 80611466790
5 Digit UPC: 59033
$30.71 ($0.31 / Count)
Hurry up! Current stock:

Product Description

Downloads

Specifications

Country of OriginUnited States
Barrel Length (Imperial)0.25 Inch
Maximum Conductor Size (Imperial)14 AWG
Terminal StyleBlock
Insulation MaterialVinyl
Maximum Insulation Outer Diameter (Imperial)0.17
Barrel Inside Diameter0.090 Inch
Overall Length (Imperial)0.85
Overall Length (Imperial) UOMin
Overall Width (Imperial)0.3
Maximum Insulation Outer Diameter (Imperial) UOMin
Stud Diameter (Imperial)0.164
Barrel StyleButted
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
UL File NumberE70512
Packaging100 per bottle
Terminal TypeFork
Stud Size#8
Maximum Conductor Size (Metric)2.08 mm²
Maximum Operating Temperature (Celsius)105.0
Minimum Conductor Size (Metric)1.31 mm²
Dimension E0.7 Inch
Stud Diameter (Metric) UOMmm
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Stud Diameter (Metric)4.166
Minimum Conductor Size (Imperial)16 AWG
Clearance (C)0.25 Inch
Units per Case500.0
Stud Diameter (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit)221.0
Fork TypeBlock
Maximum Operating Temperature (Fahrenheit) UOMDegree
