3M Products & Supplies

3M™ Scotchlok™ Female Disconnect, Nylon Fully Insulated w/Insulation Grip MNG14-187DFIK, 16-14 AWG, MNG14-187DFIK, 1000/Case - 7100164060

Sold As: 1000-Pack
SKU: 7100164060
MPN: 7100164060
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007159759
3M ID: 80610047583
5 Digit UPC: 15975
$674.24 ($0.67 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 22-18 AWG and has case quantities of 500 per case.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Nylon-insulated, butted-seam barrel with a funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
  • Allows for quick and easy disconnect of wires
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Dents and rolled edges of this female disconnect terminal offer excellent holding force
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Barrel Length (Imperial)0.25 Inch
Diameter (D)0.23 Inch
UL File NumberE70512
Overall Diameter (Imperial)0.23
Overall Width (Imperial) UOMin
Overall Width (Imperial)0.3
Packaging1000 per bulk box
Fastener OrientationFemale
Connection Width (Metric)4.75
Insulation MaterialNylon with Insulation Grip
Maximum Conductor Size (Metric)2.5 mm²
Terminal TypeDisconnect
Overall Diameter (Imperial) UOMin
Mates with Male Tab Width (W')0.187 Inch
Minimum Conductor Size (Imperial)16 AWG
Overall Length (Imperial) UOMin
Terminal StyleFully Insulated
Connection Width (Metric) UOMmm
Barrel Inside Diameter0.085 Inch
Maximum Insulation Outer Diameter (Imperial) UOMin
Connection Width (Imperial) UOMin
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Metric)1.5 mm²
Mates with Female Width0.187 Inch
Overall Length (Imperial)0.81
Barrel StyleButted
Pad Width0.187
Tab Width0.250
Disconnect TypeFemale
Maximum Insulation Outer Diameter (Imperial)0.145
Units per Case1000.0
Connection Width (Imperial)0.187
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
