3M Products & Supplies

3M™ Scotchlok™ Fork Nylon Insulated, 100/bottle, MNG14-10FX, wider-tongue design for use on free-standing studs, 500/Case - 7010351121

Sold As: 500-Pack
SKU: 7010351121
MPN: 7010351121
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128586679
3M ID: 80611458128
5 Digit UPC: 58667
$561.87 ($1.12 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Fork Terminal has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Wider tongue design for use on free-standing studs
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Electrolytic copper construction offers good conductivity
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)

Downloads

Specifications

Country of OriginUnited States
Terminal TypeFork
Clearance (C)0.29 Inch
Units per Case500.0
UL File NumberE23438
Stud Diameter (Metric) UOMmm
Maximum Conductor Size (Metric)2.08 mm²
Maximum Operating Temperature (Celsius)105.0
Maximum Insulation Outer Diameter (Imperial) UOMin
Maximum Insulation Outer Diameter (Imperial)0.145
Minimum Conductor Size (Imperial)16 AWG
Fork TypeStandard
Maximum Operating Temperature (Fahrenheit) UOMDegree
Stud Size#10
Packaging100 per bottle
Overall Length (Imperial) UOMin
Stud Diameter (Metric)4.826
Maximum Conductor Size (Imperial)14 AWG
Insulation MaterialNylon with Insulation Grip
Dimension E0.75 Inch
Barrel StyleButted
Maximum Operating Temperature (Fahrenheit)221.0
Terminal StyleStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Overall Width (Imperial) UOMin
Barrel Inside Diameter0.070 Inch
Minimum Conductor Size (Metric)1.31 mm²
Maximum Operating Temperature (Celsius) UOMDegree
Overall Length (Imperial)0.91
Stud Diameter (Imperial)0.19
Stud Diameter (Imperial) UOMin
Overall Width (Imperial)0.34
