3M Products & Supplies

3M™ Scotchlok™ Fork Nylon Insulated, 100/bottle, MNG18-10FX, wider-tongue design for use on free-standing studs, 500/Case - 7010398199

Sold As: 500-Pack
SKU: 7010398199
MPN: 7010398199
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 10051128588588
3M ID: 80611465040
5 Digit UPC: 58858
$651.82 ($1.30 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Fork Terminal has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Electrolytic copper construction offers good conductivity
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Wider tongue design for use on free-standing studs

Downloads

Specifications

Country of OriginUnited States
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Overall Width (Imperial) UOMin
Maximum Insulation Outer Diameter (Imperial)0.145
Stud Size#10
Maximum Operating Temperature (Fahrenheit)221.0
Barrel Length (Imperial)0.25 Inch
Minimum Conductor Size (Imperial)22 AWG
Stud Diameter (Imperial)0.19
Terminal StyleStandard
Stud Diameter (Metric)4.826
Dimension E0.73 Inch
Minimum Conductor Size (Metric)0.326 mm²
Maximum Operating Temperature (Celsius) UOMDegree
UL File NumberE70512
Terminal TypeFork
Insulation MaterialNylon with Insulation Grip
Overall Width (Imperial)0.34
Maximum Conductor Size (Imperial)18 AWG
Overall Length (Imperial) UOMin
Fork TypeStandard
Barrel Inside Diameter0.07 Inch
Packaging100 per bottle
Units per Case500.0
Overall Length (Imperial)0.89
Maximum Conductor Size (Metric).0823 mm²
Stud Diameter (Imperial) UOMin
Maximum Operating Temperature (Celsius)105.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Maximum Insulation Outer Diameter (Imperial) UOMin
Barrel StyleButted
Clearance (C)0.29 Inch
Stud Diameter (Metric) UOMmm
