3M™ Scotchlok™ Fork Nylon Insulated, 100/bottle, MNG18-8FX, wider-tongue design for use on free-standing studs, 500/Case - 7010291869

Sold As: 500-Pack
SKU: 7010291869
MPN: 7010291869
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 10051128586515
3M ID: 80611457963
5 Digit UPC: 58651
$651.82 ($1.30 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Fork Terminal has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Electrolytic copper construction offers good conductivity
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Wider tongue design for use on free-standing studs
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires

Downloads

Specifications

Country of OriginUnited States
Minimum Conductor Size (Metric)0.326 mm²
Insulation MaterialNylon with Insulation Grip
Clearance (C)0.29 Inch
Stud Diameter (Imperial) UOMin
Overall Width (Imperial) UOMin
Dimension E0.73 Inch
Stud Size#8
Maximum Insulation Outer Diameter (Imperial) UOMin
Packaging100 per bottle
Minimum Conductor Size (Imperial)22 AWG
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Conductor Size (Imperial)18 AWG
Fork TypeStandard
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial)0.89
Barrel Inside Diameter0.070 Inch
Barrel StyleButted
Stud Diameter (Metric)4.166
Units per Case500.0
Maximum Operating Temperature (Celsius)105.0
Maximum Insulation Outer Diameter (Imperial)0.145
UL File NumberE23438
Maximum Operating Temperature (Celsius) UOMDegree
Stud Diameter (Imperial)0.164
Overall Width (Imperial)0.34
Overall Length (Imperial) UOMin
Stud Diameter (Metric) UOMmm
Maximum Conductor Size (Metric).0823 mm²
Terminal StyleStandard
Maximum Operating Temperature (Fahrenheit)221.0
Terminal TypeFork
