3M™ Scotchlok™ Fork Nylon Insulated, 50/bottle, MNG10-8FX, wider-tongue design for use on free-standing studs, 500/Case - 7000133298

Sold As: 500-Pack
SKU: 7000133298
MPN: 7000133298
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128586884
3M ID: 80611458334
5 Digit UPC: 58688
$618.09 ($1.24 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Fork Terminal has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Electrolytic copper construction offers good conductivity
  • Wider tongue design for use on free-standing studs
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance

Downloads

Specifications

Country of OriginUnited States
Product ColorYellow
Barrel StyleButted
Overall Length (Imperial)1.03
Overall Width (Imperial) UOMin
Maximum Insulation Outer Diameter (Imperial)0.25
Maximum Conductor Size (Imperial)10 AWG
Dimension E0.84 Inch
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Maximum Conductor Size (Metric)5.26 mm²
Overall Length (Metric) UOMmm
Overall Width (Metric)9.6
Overall Width (Imperial)0.38
Overall Length (Metric)26.16
Terminal TypeFork
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Conductor Size (Metric)3.31 mm²
Fork TypeStandard
Stud Size#8
Maximum Operating Temperature (Fahrenheit)221.0
Maximum Insulation Outside Diameter0.145 in
Maximum Insulation Outer Diameter (Metric)3.7
Maximum Insulation Outer Diameter (Imperial) UOMin
Terminal StyleStandard
Minimum Conductor Size (Imperial)12 AWG
Clearance (C)0.29 Inch
Maximum Recommended Voltage Rating600.0
Overall Length (Imperial) UOMin
Barrel Inside Diameter0.135 Inch
Packaging50 per bottle
Maximum Insulation Outer Diameter (Metric) UOMmm
Units per Case500.0
UL File NumberE23438
Insulation MaterialNylon with Insulation Grip
Maximum Recommended Voltage Rating UOMV
Maximum Operating Temperature (Celsius) UOMDegree
MaterialETP Copper
Maximum Operating Temperature (Celsius)105.0
