3M™ Scotchlok™ Ring Tongue Nylon Insulated Brazed Seam MN8-516RK, Stud Size 5/16, 200/Case - 7000132144

Sold As: 200-Pack
SKU: 7000132144
MPN: 7000132144
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007082699
3M ID: 80008006050
5 Digit UPC: 8269
$224.75 ($1.12 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Ring Tongue Terminal ensures an ideal fit while offering reliable and safe performance. The terminal has a nylon-insulated, brazed-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Flared portion of the nylon sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Standard-style ring tongue fits around the stud
  • Nylon-insulated, brazed-seam barrel ensures a secure fit and offers reliable performance
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Maximum Voltage Rating600 to 1000 V
Connection Width (Imperial) UOMin
Maximum Recommended Voltage Rating600.0
Overall Length (Imperial) UOMin
Connection TypeCrimp
Minimum Conductor Size (Imperial)8 AWG
Overall Length (Imperial)1.38
Maximum Conductor Size (Metric)8.37
Terminal StyleStandard
Connection Width (Imperial)0.315
Connection Width (Metric) UOMmm
Operating Temperature (Fahrenheit)-40 °F to 221 °F
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Conductor Size (Metric)8.37 mm²
Maximum Recommended Voltage Rating UOMV
Ring TypeStandard
Terminal TypeRing
Operating Temperature Range (Celsius)-40 °C to 105 °C
UL File NumberE23438
Maximum Operating Temperature (Celsius)105.0
Barrel Length (Imperial)0.39 Inch
Operating Temperature Range (Fahrenheit)-40 °F to 221 °F
Connection Width (Metric)8.0
Overall Width (Imperial)0.59
Maximum Operating Temperature (Fahrenheit) UOMDegree
Barrel StyleBrazed Seam
Maximum Operating Temperature (Fahrenheit)221.0
Insulation MaterialNylon
Maximum Conductor Size (Imperial)8 AWG
Product ColorRed
Overall Width (Imperial) UOMin
