3M Products & Supplies

3M™ Thermally Conductive Epoxy Adhesive TC2810, 400mL DuoPak - 7100192221

Sold As: 80-Pack
SKU: 7100192221
MPN: 7100192221
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 08887862345812
3M ID: XA006804562
5 Digit UPC: 34581
$61,988.46 ($774.86 / Count)
Hurry up! Current stock:

Product Description

3M™ Thermally Conductive Epoxy Adhesive TC-2810 is a thermally conductive 2-part epoxy using boron nitride(BN) filler for good thermal conductivity with high adhesion.

Features

  • Good gap filling
  • Slight tack allows pre-assembly
  • High adhesive strength
  • Thin bonding line
  • Low viscosity for potting application
  • Good surface wet out
Spec Sheet



Downloads

Specifications

Shelf Life365
Country of OriginSingapore
Application Temperature To (Celsius)120.0
Volume (Metric)400.0
Container TypeCartridge
Minimum Cure Conditions (Celsius)23.0
Volume (Imperial) UOMfl
Net Weight (Metric)4.54
Volume (Imperial)13.53
Application Temperature From (Celsius)23.0
ApplicationBonding; Gap Filling; Potting; Thermal Transfer
Adhesion Strength (Imperial)0.0
Net Weight (Imperial)10.0
Density0.0
IndustriesElectronics
Shear Strength UOMpsi
Net Weight (Metric) UOMkg
Shelf Life UOMMonth
Accelerator ColorOff-white
Hardness75 - 80 Shore D
Storage Temperature (Celsius)21°C
Application Temperature To (Celsius) UOMDegree
Units per Case2.0
Paint Time0.0
Full Cure Temperature (Celsius)23.0
Container Size (Metric)400.0 mL
Adhesive TypeEpoxy
Net Weight (Imperial) UOMlb
Full Cure Temperature (Fahrenheit)73.0
Volume (Metric) UOMmL
Minimum Cure Conditions (Fahrenheit)73.0
Mix Ratio Volume Base:Accelerator2:1
Full Cure Time24 Hours @ 73 F (23 C)
Adhesion Strength (Metric)0.0
Container Size (Imperial)13.53 fl oz
Application Temperature From (Celsius) UOMDegree
Shear Strength2700.0
