3M Products & Supplies

3M™ Thermally Conductive Epoxy Adhesive TC2810 Part B, 5-gal (24 kg) Pail - 7100159367

SKU: 7100159367
MPN: 7100159367
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 08887719303729
3M ID: XA004193299
5 Digit UPC: 30372
$27,977.34 each
Hurry up! Current stock:

Product Description

3M™ Thermally Conductive Epoxy Adhesive TC-2810 is a thermally conductive 2-part epoxy using boron nitride(BN) filler for good thermal conductivity with high adhesion.

Features

  • Low viscosity for potting application
  • Slight tack allows pre-assembly
  • Good gap filling
  • High adhesive strength
  • Thin bonding line
  • Good surface wet out
Spec Sheet



Downloads

Specifications

Shelf Life365
Country of OriginSingapore
Container TypePail
Volume (Metric) UOML
Container Size (Imperial)52.91 lb
Full Cure Time24 Hours @ 73 F (23 C)
Net Weight (Imperial)10.0
Minimum Cure Conditions (Celsius)23.0
Application Temperature To (Celsius) UOMDegree
Units per Case1.0
ApplicationBonding; Gap Filling; Potting; Thermal Transfer
Application Temperature From (Celsius) UOMDegree
Mix Ratio Volume Base:Accelerator2:1
Volume (Metric)18.93
Shelf Life UOMMonth
Shear Strength2700.0
Adhesion Strength (Imperial)0.0
Adhesive TypeEpoxy
Paint Time0.0
Hardness75 - 80 Shore D
Storage Temperature (Celsius)21°C
Full Cure Temperature (Fahrenheit)73.0
Net Weight (Metric) UOMkg
Density0.0
Full Cure Temperature (Celsius)23.0
IndustriesElectronics
Container Size (Metric)24.0 kg
Net Weight (Imperial) UOMlb
Volume (Imperial) UOMgal
Minimum Cure Conditions (Fahrenheit)73.0
Accelerator ColorOff-white
Volume (Imperial)5.0
Application Temperature To (Celsius)120.0
Application Temperature From (Celsius)23.0
Adhesion Strength (Metric)0.0
Shear Strength UOMpsi
Net Weight (Metric)4.54
