3M Products & Supplies

3M™ Thermally Conductive Epoxy Adhesive TC2810 Part A, 5-gal (23 kg) Pail - 7100149199

SKU: 7100149199
MPN: 7100149199
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 58887719303717
3M ID: XA004193281
5 Digit UPC: 30371
$29,030.08 each
Hurry up! Current stock:

Product Description

3M™ Thermally Conductive Epoxy Adhesive TC 2810 is a thermally conductive 2 part epoxy using boron nitride(BN) filler for good thermal conductivity with high adhesion.

Features

  • High adhesive strength
  • Slight tack allows pre-assembly
  • Thin bonding line
  • Low viscosity for potting application
  • Good surface wet out
  • Good gap filling
Spec Sheet



Downloads

Specifications

Shelf Life365
Country of OriginSingapore
Container Size (Metric)23.0 kg
Paint Time0.0
Net Weight (Metric)4.54
Minimum Cure Conditions (Fahrenheit)73.0
Shear Strength2700.0
Storage Temperature (Celsius)21°C
Density0.0
Minimum Cure Conditions (Celsius)23.0
Container Size (Imperial)50.71 lb
Application Temperature From (Celsius)23.0
Application Temperature To (Celsius) UOMDegree
Mix Ratio Volume Base:Accelerator2:1
Full Cure Temperature (Fahrenheit)73.0
Net Weight (Metric) UOMkg
Net Weight (Imperial) UOMlb
Volume (Imperial) UOMgal
ApplicationBonding; Gap Filling; Potting; Thermal Transfer
Adhesion Strength (Imperial)0.0
IndustriesElectronics
Application Temperature From (Celsius) UOMDegree
Adhesive TypeEpoxy
Container TypePail
Net Weight (Imperial)10.0
Shelf Life UOMMonth
Full Cure Time24 Hours @ 73 F (23 C)
Volume (Metric) UOML
Hardness75 - 80 Shore D
Shear Strength UOMpsi
Full Cure Temperature (Celsius)23.0
Volume (Imperial)5.0
Accelerator ColorOff-white
Units per Case1.0
Adhesion Strength (Metric)0.0
Volume (Metric)18.93
Application Temperature To (Celsius)120.0
