3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 6 in x 18 yd, 3 in Paper Core, 2 Rolls/Case - 7010319576

Sold As: 2-Pack
SKU: 7010319576
MPN: 7010319576
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128570548
3M ID: 80611436488
5 Digit UPC: 57054
$1,155.25 ($577.63 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Comes on a removable liner for easy die-cutting and handling
  • Rated for 600V applications
  • Suitable for grounding and EMI shielding equipment, components and shielded rooms
  • Flame-retardant
  • Unique adhesive creates secure contact with the application surface

Specifications

Shelf Life1825
Country of OriginTaiwan
ApplicationShielding
Tape GradeProfessional
Overall Width (Imperial)6.0
Backing (Carrier) Thickness (Imperial)1.4
Overall Width (Imperial) UOMin
Shelf Life UOMYear
Adhesive TypeConductive Acrylic
Product ColorTin
Product MarketsElectrical Equipment Manufacturing
Total Tape Thickness without Liner (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Width (Metric) UOMmm
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
MaterialTin Plated Copper Foil
Tensile Strength (Metric) UOMN/cm
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Total Tape Thickness without Liner (Metric)0.066
Tensile Strength (Metric)44.0
Backing (Carrier) Thickness (Metric)0.035
Overall Width (Metric)152.4
