3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 2 in x 18 yd, 3 in Paper Core, 5 Rolls/Case - 7010320385

Sold As: 5-Pack
SKU: 7010320385
MPN: 7010320385
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138499990
3M ID: 80610885768
5 Digit UPC: 49999
$1,029.71 ($205.94 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Comes on a removable liner for easy die-cutting and handling
  • Flame-retardant
  • Rated for 600V applications
  • Unique adhesive creates secure contact with the application surface
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Suitable for grounding and EMI shielding equipment, components and shielded rooms

Specifications

Shelf Life1825
Country of OriginTaiwan
Product ColorTin
Tape GradeProfessional
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.066
Backing (Carrier) Thickness (Metric) UOMmm
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Overall Width (Imperial)2.0
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Imperial)1.4
Overall Width (Metric) UOMmm
Tensile Strength (Metric)44.0
Shelf Life UOMYear
Tensile Strength (Metric) UOMN/cm
Adhesive TypeConductive Acrylic
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Width (Metric)50.8
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
Product MarketsElectrical Equipment Manufacturing
Backing (Carrier) Thickness (Metric)0.035
MaterialTin Plated Copper Foil
ApplicationShielding
