3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 2-1/2 in x 18 yd, 3 in Paper Core, 5 Rolls/Case - 7010397204

Sold As: 5-Pack
SKU: 7010397204
MPN: 7010397204
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051135895405
3M ID: 80611087000
5 Digit UPC: 89540
$1,287.13 ($257.43 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Suitable for grounding and EMI shielding equipment, components and shielded rooms
  • Comes on a removable liner for easy die-cutting and handling
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Flame-retardant
  • Rated for 600V applications
  • Unique adhesive creates secure contact with the application surface

Specifications

Shelf Life1825
Country of OriginTaiwan
MaterialTin Plated Copper Foil
Backing (Carrier) Thickness (Imperial)1.4
Product MarketsElectrical Equipment Manufacturing
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric)0.066
Overall Width (Metric) UOMmm
ApplicationShielding
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Tape GradeProfessional
Shelf Life UOMYear
Overall Width (Metric)63.5
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Imperial)2.5
Product ColorTin
Tensile Strength (Metric)44.0
Backing (Carrier) Thickness (Metric)0.035
Adhesive TypeConductive Acrylic
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Metric) UOMmm
Tensile Strength (Metric) UOMN/cm
