3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 1 in x 18 yd, 3 in Paper Core, 9 Rolls/Case - 7010320384

Sold As: 9-Pack
SKU: 7010320384
MPN: 7010320384
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138498733
3M ID: 80610884506
5 Digit UPC: 49873
$815.86 ($90.65 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Flame-retardant
  • Comes on a removable liner for easy die-cutting and handling
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Rated for 600V applications
  • Unique adhesive creates secure contact with the application surface
  • Suitable for grounding and EMI shielding equipment, components and shielded rooms
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginTaiwan
Adhesive TypeConductive Acrylic
ApplicationShielding
Tensile Strength (Metric) UOMN/cm
Product ColorTin
Total Tape Thickness without Liner (Metric)0.066
Overall Length (Metric)16.5
Overall Width (Imperial)1.0
Tape GradeProfessional
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
MaterialTin Plated Copper Foil
Shelf Life UOMYear
Tensile Strength (Metric)44.0
Overall Length (Imperial) UOMyd
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
Overall Length (Imperial)18.0
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Imperial)1.6
Overall Length (Metric) UOMm
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Backing (Carrier) Thickness (Metric)0.04
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Width (Metric)25.0
Product MarketsElectrical Equipment Manufacturing
Total Tape Thickness without Liner (Metric) UOMmm
