3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 1/4 in x 18 yd, 3 in Paper Core, 36 Rolls/Case - 7010350298

Sold As: 36-Pack
SKU: 7010350298
MPN: 7010350298
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138498696
3M ID: 80610884464
5 Digit UPC: 49869
$842.02 ($23.39 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Flame-retardant
  • Comes on a removable liner for easy die-cutting and handling
  • Rated for 600V applications
  • Suitable for grounding and EMI shielding equipment, components and shielded rooms
  • Unique adhesive creates secure contact with the application surface
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginTaiwan
Overall Width (Imperial) UOMin
Overall Width (Metric)6.35
Overall Width (Metric) UOMmm
Adhesive TypeConductive Acrylic
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Imperial)0.25
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Imperial)1.6
Overall Length (Metric) UOMm
MaterialTin Plated Copper Foil
Overall Length (Imperial)18.0
Overall Length (Imperial) UOMyd
Product ColorTin
Tensile Strength (Metric) UOMN/cm
Overall Length (Metric)16.5
Product MarketsElectrical Equipment Manufacturing
Tape GradeProfessional
Tensile Strength (Metric)44.0
Shelf Life UOMYear
Backing (Carrier) Thickness (Metric)0.04
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
ApplicationShielding
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.066
